Model: DPAC 600
| Cooling Capacity |
600 Watts |
| Type of Refrigerant |
R-134a CFC Free |
| Amount of Refrigerant |
200 gms |
| Thermostat Setting |
25*C - 50*C |
| Rated Frequency |
50 Hz |
| Standard Power Supply |
23V/1 Phase |
| Current |
3 Amps |
| Weight |
35 Kgs |
| Height X Width X Depth mm |
700 X 270 X 220 mm |
| Ambient Air Temperature |
25*C - 40*C |
| Compressor |
Scroll Compressor |
| Condeser Fan |
FansTech 175mm |
| Evaporator Fan |
Fanstech 133mm |
| MCB Protection |
NA |
| Body |
MS with power coated |
Model: DPAC 1000
| Cooling Capacity |
1000 Watts |
| Type of Refrigerant |
R-134a CFC Free |
| Amount of Refrigerant |
250 gms |
| Thermostat Setting |
25*C - 50*C |
| Rated Frequency |
50 Hz |
| Standard Power Supply |
23V/1 Phase |
| Current |
3.4 Amps |
| Weight |
45 Kgs |
| Height X Width X Depth mm |
800 X 370 X 270 mm |
| Ambient Air Temperature |
25*C - 40*C |
| Compressor |
Scroll Compressor |
| Condeser Fan |
FansTech 220mm |
| Evaporator Fan |
Fanstech 190mm |
| MCB Protection |
1 Pole 10 Amp |
| Body |
MS with power coated |
Model: DPAC 1500
| Cooling Capacity |
1500 Watts |
| Type of Refrigerant |
R-134a CFC Free |
| Amount of Refrigerant |
250 gms |
| Thermostat Setting |
25*C - 50*C |
| Rated Frequency |
50 Hz |
| Standard Power Supply |
23V/1 Phase |
| Current |
4.2 Amps |
| Weight |
45 Kgs |
| Height X Width X Depth mm |
815 X 370 X 270 mm |
| Ambient Air Temperature |
25*C - 40*C |
| Compressor |
Scroll Compressor |
| Condeser Fan |
FansTech 175mm |
| Evaporator Fan |
Fanstech 133mm |
| MCB Protection |
1 Pole 10 Amp |
| Body |
MS with power coated |
DPAC 2000
| Cooling Capacity |
2000 Watts |
| Type of Refrigerant |
R-134a CFC Free |
| Amount of Refrigerant |
350 gms |
| Thermostat Setting |
25*C - 50*C |
| Rated Frequency |
50 Hz |
| Standard Power Supply |
23V/1 Phase |
| Current |
5 Amps |
| Weight |
55 Kgs |
| Height X Width X Depth mm |
950 X 380 X 270 mm |
| Ambient Air Temperature |
25*C - 40*C |
| Compressor |
Scroll Compressor |
| Condeser Fan |
FansTech 225mm |
| Evaporator Fan |
Fanstech 220 mm |
| MCB Protection |
1 Pole 10 Amp |
| Body |
MS with power coated |
DPAC 2700
| Cooling Capacity |
2700 Watts |
| Type of Refrigerant |
R-134a CFC Free |
| Amount of Refrigerant |
650 |
| Thermostat Setting |
25*C - 50*C |
| Rated Frequency |
50 Hz |
| Standard Power Supply |
23V/1 Phase |
| Current |
5 Amps |
| Weight |
65 Kgs |
| Height X Width X Depth mm |
950 X 380 X 270 mm |
| Ambient Air Temperature |
25*C - 40*C |
| Compressor |
Scroll Compressor |
| Condeser Fan |
FansTech 225mm |
| Evaporator Fan |
Fanstech 220mm |
| MCB Protection |
1 Pole 10 Amp |
| Body |
MS with power coated |
DPAC 3500
| Cooling Capacity |
3500 Watts |
| Type of Refrigerant |
R-134a CFC Free |
| Amount of Refrigerant |
750 gms |
| Thermostat Setting |
25*C - 50*C |
| Rated Frequency |
50 Hz |
| Standard Power Supply |
23V/1 Phase |
| Current |
7.5 Amps |
| Weight |
85 Kgs |
| Height X Width X Depth mm |
1079 X 455 X 380 mm |
| Ambient Air Temperature |
25*C - 40*C |
| Compressor |
Scroll Compressor |
| Condeser Fan |
FansTech 250mm |
| Evaporator Fan |
Fanstech 270mm |
| MCB Protection |
1 Pole 10 Amp |
| Body |
MS with power coated |
